MSI GeForce RTX 3060 VENTUS 2X 8G OC

GeForce RTX™ 3060 VENTUS 2X 8G OC

The GeForce RTX™ 3060 lets you take on the latest games using the power of Ampere—NVIDIA's 2nd generation RTX architecture. Get incredible performance with enhanced Ray Tracing Cores and Tensor Cores, new streaming multiprocessors, and high-speed G6 memory.

Boost Clock / Memory Speed

• 1807 MHz / 15 Gbps
• 8GB GDDR6
• DisplayPort x 3
• HDMI x 1 (Supports 4K@120Hz as specified in HDMI 2.1)

Dual Fan Thermal Design - TORX Fan 3.0: The award-winning MSI TORX Fan 3.0 design creates high static pressure and pushes the limits of thermal performance.

Afterburner - Take full control with the most recognized and widely used graphics card overclocking software in the world.

MSI Center - The exclusive MSI Center software lets you monitor, tweak and optimize MSI products in real-time.

MODEL NAME

GeForce RTX™ 3060 VENTUS 2X 8G OC

GRAPHICS PROCESSING UNIT

NVIDIA GeForce RTX™ 3060

INTERFACE

PCI Express Gen 4

CORE CLOCKS

Boost: 1807 MHz

CUDA CORES 3584 Units

MEMORY SPEED 15 Gbps

MEMORY 8GB GDDR6

MEMORY BUS 128-bit

OUTPUT

DisplayPort x 3 (v1.4a) / HDMI x 1 (Supports 4K@120Hz as specified in HDMI 2.1)

HDCP SUPPORT

Y

POWER CONSUMPTION 170 W

POWER CONNECTORS 8-pin x 1

RECOMMENDED PSU 550 W

CARD DIMENSION (MM) 235 x 124 x 42 mm

WEIGHT (CARD / PACKAGE) 675 g / 1030 g

DIRECTX VERSION SUPPORT 12 Ultimate

OPENGL VERSION SUPPORT 4.6

MAXIMUM DISPLAYS 4

VR READY

Y

G-SYNC TECHNOLOGY

Y

ADAPTIVE VERTICAL SYNC

Y

DIGITAL MAXIMUM RESOLUTION 7680 x 4320
